    The Epson
  printer ESC/P & ESC/P2 Printer Codes



Many printer code lists are either in code order (OK for hacking but useless for setting up a print job!) or grouped in types (so for 'bold print' you would need to first find out then always remember that it's in the 'style' group (or some other name); for a new line you would probably have to know that it's in the 'move' group. But THIS list is in simple alphabetic order of the function needed. So, if, for example, you want to start a new line, you simply look under N for New Line.

Many functions are entered several times under different names, eg, 'new line' is also under 'line feed' because not everyone uses the same definitions. If any of YOUR preferred definitions are not there you can edit or add to the list in a web page editor or in any plain ASCII text editor if you know how to edit simple html text.

The codes themselves are decimal values (separated by commas where there is more than one value for a function). They can be used from most programming languages as well as some applications such as text editors which permit you to enter printer codes.

Typically in BASIC you would enter them by using LPRINT CHR$(n). For example, to print with emphasised characters, the codes are 27,69 which would be entered in BASIC as LPRINT CHR$(27);CHR$(69).

Note that when a value is the ASCII code for a quotable character then the character can be used (within quotes) instead. So, whereas 27 is not quotable, 69 is because it is the ASCII value for the capital letter "E". So, instead of LPRINT CHR$(27);CHR$(69) you could, if you prefer, use LPRINT CHR$(27);"E" which sends exactly the same codes to a printer.

Where a code uses 0 and 1 as ON and OFF flags then you can normally use 48 ("0") and 49 ("1") as alternatives.

Some BASIC language versions in some modes always add a line feed after LPRINT. If you keep getting extra line spaces then you might try adding a semi-colon (;) at the end of the LPRINT string, for example, LPRINT CHR$(27);CHR$(69);

QUICK BASIC has some terrible quirks if sending codes. You might well find it sending a line feed code in the middle of sending graphic data! If you get problems with some codes not doing what they should then instead of LPRINT try instead the following...

OPEN "PRN" FOR BINARY AS #3
PRINT #3;CHR$(27);CHR$(69);

The above 'OPEN' line need only be used once at the start of the program and need not be used before every PRINT #.

The #3 at the end of the 'OPEN' line can be any value from 1 to 15 but you cannot use the same number as is being used for some other operation at the same time (eg, if you have opened a file for reading or writing).

"LPT1" or "LPT2" can be used instead of "PRN" but "PRN" works for both whereas "LPT1" would fail on a system configured for "LPT2"

In BASIC, string variables can be used to represent codes, for example..

esc$=CHR$(27)
emph$=esc$+"E"
emphOFF$=esc$+"F"
dubStrike$=esc$+"G"
dubStrikeOFF$=esc$+"H"

Then you can build up multiples like...

bold$=emph$ + dubStrike$
boldOFF$=emphOFF$+dubStrikeOFF$

Thus, when you want to print in bold print...

LPRINT "This is "; bold$;"bold";boldOFF$

In the list, variable codes are represented by labels which you need to replace with actual values (or programming varaibles) when used. For example, you might substitute 5 for n (depending on what you want to achieve and what the range of the parameter allows). Where more explanation is needed an asterisk with a number is shown, eg, *1 and *2. Details of these are explained at the end of the list.

In the list, lo, hi means a two byte value between 0 and 65535. You replace lo and hi with the values you want. To calculate lo and hi, take your original value (example: the length of image data, let's say 700 bytes long. Divide it by 256 which is 2 and a remainder of 188. hi is the 2 and lo is the remainder so it would be put in as 188,2 to replace lo,hi when actually applying any of the code sequences listed below. lo,hi must never be greater than the graphics mode selected will allow of dots on one line.

Not all printers will implement all the codes nor is the list complete so some printers might implement more codes. The list shows the most commonly-used codes.

These codes will not be effective from many Windows programs (that is, from the user's point of view) so don't expect Notepad to print wide print after you have sent the wide code!

Some codes are not implemented immediately but for example after the next line feed. So if nothing seems to happen it does not necessarily mean there is a fault. However, if when printing images you do not send the correct data length, the printer might be expecting more image data and will treat further codes or even text as more image data. This might be buffered and the printer will do nothing. Even using 27,64 will not clear the printer; you might have to switch it off or send enough image data.

Here's the reference list...



The Epson ESC/P & ESC/P2 Printer Codes
DECIMAL CODES
FUNCTION (ALPHABETICAL ORDER)
27,52 Alternate characters ON (usually italic) *2
27,53 Alternate characters OFF *2
8 Back Space
27,85,0 Bi-directional printing
7 Beep or bell
27,114,0 Black ink
27,69 Bold semi (emphasized) characters ON
27,70 Bold semi (emphasized) characters OFF
27,85,0 Both directions printing
27,78,n Bottom margin n lines ON *4
27,79 Bottom margin OFF *4
24 Cancel line
13 Carriage Return (return to start of line)
27,97,1 Centre text
27,105,1 Character-by-character printing (immediate)
27,52 Characters (alternate) ON *2 (usually italic)
27,53 Characters (alternate) OFF *2
27,82,n Characters (national) set n *5
27,37,0 character set = normal
27,37,1 character set = user-defined
27,38,n,n,n... character set DEFINE
27,58,0 character set Roman to RAM
27,58,1 characters Sans Serif to RAM
27,64 Clear all codes
127 Clear printer buffer
27,114,0 Colour Black
27,114,1 Colour Magenta
27,114,2 Colour Cyan
27,114,3 Colour Violet
27,114,4 Colour Yellow
27,114,5 Colour Red
27,114,6 Colour Green
15 Condensed Characters ON
18 Condensed Characters OFF
27,114,2 Cyan ink
27,64 Defaults set all (initialize printer)
127 Delete (from buffer) last character
24 Delete(from buffer) last line
19 Deselect printer
27,71 Double-strike ON
27,72 Double-strike OFF
14 Double-width characters ON *6
20 Double-width characters OFF *6
27,87,1 Double-width characters ON *6
27,87,0 Double-width characters OFF *6
27,101,1,n Down tab SET n (regular)
27,66,n,n,n... Down tab SET (irregular)
27,98,c,n,n... Down tab SET channels
27,47,c Down tab channel SELECT
11 Down tab as set
27,102,1,n Down tab n lines
120,0 Draft quality ON (LQ or NLQ off) *8
120,1 Draft quality OFF (LQ or NLQ) *8
27,25,82 Eject page
27,77 Elite (12 cpi) characters ON
27,80 Elite (12 cpi) characters OFF
27,69 Emphasized characters ON
27,70 Emphasized characters OFF
27,56 Empty paper disable
27,57 Empty paper enable
127 Empty the printer buffer
14 Enlarged (wide) characters ON (one-line) *6
20 Enlarged (wide) chars OFF (one-line) *6
27,87,1 Enlarged characters ON *6
27,87,0 Enlarged characters OFF *6
127 Erase (from buffer) last character
24 Erase (from buffer) last line
27,115,1 Faint/fast print ON
27,115,0 Faint/fast print OFF
27,115,1 Fast/half-tone ON
27,115,0 Fast/half-tone OFF
27,115,1 Feint/fast print ON
27,115,0 Feint/fast print OFF
27,37,0 font = normal
27,37,1 font = user-defined
27,116,n Font select n
12 Feed Form (form feed)
12 Feed Page (form feed)
12 Feed Sheet (form feed)
27,38,n,n,n... font DEFINE
27,58,0 font Roman to RAM
27,58,1 font Sans Serif to RAM
12 Form Feed (new page)
27,67,n Form length n lines
27,67,0,n Form length n inches
27,42,*1,lo,hi Graphics (variable resolution)
27,75,lo,hi Graphics (480 dots-per-line resolution)
27,76,lo,hi Graphics (960 dots-per-line resolution)
27,89,lo,hi Graphics (960 dots-per-line faint/fast)
27,90,lo,hi Graphics (1920 dots-per-line resolution)
27,114,6 Green ink
27,115,1 Half-tone/fast ON
27,115,0 Half-tone/fast OFF
27,60 Home (line restart)
27,42,*1,lo,hi Image mode (variable) *1
27,75,lo,hi Image (480 dots-per-line resolution)
27,76,lo,hi Image (960 dots-per-line resolution)
27,89,lo,hi Image (960 dots-per-line resolution faint/fast)
27,90,lo,hi Image (1920 dots-per-line resolution)
27,105,1 Immediate print character-by-character
27,64 Initialize printer (clear all codes)
27,52 Italic characters ON *2
27,53 Italic characters OFF *2
27,97,0 Justify left
27,97,2 Justify right
27,97,3 Justify both
27,108,n Left margin n characters
120,1 Letter quality ON *8
120,0 Letter quality OFF *8
27,105,0 Line buffering
10 Line Feed (new line)
27,105,0 Line printing (buffered)
27,60 Line restart
27,48 Line space 1/8th"
27,49 Line space 7/72th"
27,50 Line space 1/6th"
27,51,n Line space n/216th"
27,74,n Line space n/216th" *3
27,65,n Line space n/72th"
120,1 LQ letter quality ON *8
120,0 LQ letter quality OFF *8
27,114,1 Magenta ink
27,108,n Margin (left) n characters
27,81,n Margin (right) n characters
27,78,n Margin(vertical) n lines ON*4
27,79 Margin (vertical) OFF *4
27,33,n Master style select *7
27,82,n National character set n *5
10 New Line (line feed)
12 New Page (form feed)
12 New Sheet (form feed)
120,1 NLQ letter quality ON *8
120,0 NLQ letter quality OFF *8
27,107,0 NLQ font = Roman
27,107,1 NLQ font = Sans Serif
27,85,1 One-direction printing
27,56 Out of paper disable
27,57 Out of paper enable
27,106,n Page backwards n/216"
27,25,82 Page eject
12 Page feed (form feed)
27,25,49 Page feed 1 SET
27,25,50 Page feed 2 SET
27,25,70 Page front tractor SET
27,25,66 Page rear tractor SET
27,67,n Page length (n lines)
27,67,0,n Page length (n inches)
27,106,n Page upwards n/216"
27,25,82 Paper eject
27,56 Paper empty disable
27,57 Paper empty enable
12 Paper feed (form feed)
27,25,49 Paper feed 1 SET
27,25,50 Paper feed 2 SET
27,25,70 Paper front tractor SET
27,25,66 Paper rear tractor SET
27,56 Paper out disable
27,57 Paper out enable
27,67,n Paper length n lines
27,67,0,n Paper length n inches
27,78,n Perforation skip n lines ON
27,79 Perforation skip OFF
27,80 Pica (10 cpi) characters ON
27,77 Pica (10 cpi) characters OFF
27,42,*1,lo,hi Picture mode (variable)
27,75,lo,hi Picture (480 dots-per-line resolution)
27,76,lo,hi Picture (960 dots-per-line resolution)
27,89,lo,hi Picture (960 dots-per-line resolution faint/fast)
27,90,lo,hi Picture (1920 dots-per-line resolution)
17 Printer select
19 Printer deselect
27,114,5 Red ink
127 Remove (from buffer) last character
24 Remove(from buffer) last line
27,60 Restart line (home)
27,106,n Reverse line feed n/216"
27,81,n Right margin n characters
9 Right tab as set
27,101,0,n Right tab SET n (regular)
27,68,n,n,n... Right tab SET (variable)
27,107,0 Roman (NLQ font)
27,107,1 Sans Serif (NLQ font)
17 Select printer
27,69 Semi-bold (emphasized) characters ON
27,70 Semi-bold (emphasized) characters OFF
27,25,82 Sheet eject
12 Sheet feed (form feed)
27,25,49 Sheet feed 1 SELECT
27,25,50 Sheet feed 2 SELECT
27,25,70 Sheet front tractor SET
27,25,66 Sheet rear tractor SET
27,67,n Sheet length n lines
27,67,0,n Sheet length n inches
27,85,1 Single-direction print
27,78,n Skip perforation n lines ON *4
27,79 Skip perforation OFF *4
13 Start of line (CR)
27,60 Start of line (home)
27,33,n Style Master select *7
27,83,0 Superscript ON
27,84 Superscript OFF
27,83,1 Subscript ON
27,84 Subscript OFF
27,101,0,n Tab right SET n (regular)
27,68,n,n,n... Tab right SET (variable)
9 Tab right as set
27,102,0,n Tab right n characters
27,101,1,n Tab down SET n (regular)
27,66,n,n,n... Tab down SET (irregular)
27,98,c,n,n... Tab down SET channels
27,47,c Tab down channel SELECT
11 Tab down as set
27,102,1,n Tab down n lines
27,78,n Top margin n lines ON *4
27,79 Top margin OFF *4
27,85,0 Two-directional printing
27,105,1 Typewriter mode
27,45,1 Underline ON
27,45,0 Underline OFF
27,85,1 Uni-directional printing
27,106,n Upward line feed n/216"
11 Vertically tab down
27,114,3 Violet ink
14 Wide characters ON (one-line) *6
20 Wide characters OFF (one-line) *6
27,87,1 Wide characters ON *6
27,87,0 Wide characters OFF *6
27,114,4 Yellow ink



*1 is the mode in Graphics(variable resolution) The *1 should be replaced with:

0 = single density = 480 dots a line
1 = double density = 960 dots a line
2 = 1 but faint+fast = 960 dots a line
3 = quad density = 1260 dots a line
4 = screen monitor 1 = 640 dots a line
5 = screen monitor 2 = 576 dots a line
6 = screen monitor 3 = 720 dots a line

lo,hi must not be greater than the dots a line shown because that is the maximum (it can of course be less)



*2 Alternate Characters. Many printers have an alternate character set that can be switched to. Typically this might be the same character set as the main one but in italic (sloping) form.



*3 Line space n/216th" (27,74,n) is temporary for that line only and de- faults to previous setting after a line feed. That is, it clears itself. To set up n/216th" line spacing permanently (until you clear it with another code) use 27,51,n



*4 Top and Bottom margins: 27,78,n and 27,79 are actually skip perforation ON and OFF. The printer normally counts DOWN the number of lines left to print on the page (default total normally 66 but can be changed with the Page Length code).

If this skip perforation code is ON then when the printer counts down to 'n' it prints 'n' blank lines.

If you initially line up the top of the paper in line with the print head then you will get no margin at the top(unless blank lines are included in the text being printed) but 'n' blank lines at the bottom.

To get an equal margin top and bottom you need to either wind down or manually line feed the paper down half of n lines at the top of the first page (these line feeds can be included in a program that is printing a document). When the printer tries to print n blank lines at the bottom of each page it will then only print half at the bottom and half at the start of the next page.



*5 National character set. There are variations in the character set for different countries. For example, Character 35 is the hash sign "#" in the American selection but a pound sign "£" in the UK. The codes are 27,82,n where n is:

0=USA
1=France
2=Germany
3=UK
4=Denmark 1
5=Sweden
6=Italy
7=Spain 1
8=Japan
9=Norway
10=Denmark 2
11=Spain 2
12=Latin America

Probably most printers are set for USA by default. Not all printers cover all the countries shown. The first four are most common.



*6 Wide (enlarged) characters mode using 27,14 is only temporary for that line and is cleared when printing starts a new line. Likewise 27,20 only cancels one-line wide print. Wide characters using 27,87,1 are permanent until switched off with code 27,87,0.



*7 Master style select 27,33,n where n=
0=Pica (10 characters per inch)
1=Elite (12 characters per inch)
4=condensed
8=emphasised
16=Double Strike
32=Double Width
64=Italic
128=Underline



*8 Whether codes 27,120,1 will provide Letter Quality (LQ) or Near Letter Quality (NLQ) depends on your printer. 9-pin printers typically will only give NLQ. Draft quality is simply disabling LQ or NLQ to print normally.
